FH29B-100S-0.2SHW(99)
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy FH29B-100S-0.2SHW(99) with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy FH29B-100S-0.2SHW(99) with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | FH29B-100S-0.2SHW(99) |
|---|---|
| Manufacturer | Hirose |
| Description | CONN FPC BOTTOM 100POS 0.20MM |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $2.853 | $2.736 | $2.498 | $2.379 | $2.26 | |
- Product parameter
- Data sheet
Product parameter
| Part Number | FH29B-100S-0.2SHW(99) | Manufacturer | Hirose |
|---|---|---|---|
| Description | CONN FPC BOTTOM 100POS 0.20MM | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 17158 pcs | Data sheet | FH29 Series Datasheet |
| Category | Connectors, Interconnects | Voltage Rating | 40V |
| Termination | Solder | Series | FH29B |
| Pitch | 0.008" (0.20mm) | Packaging | Original-Reel® |
| Other Names | H124633DKR | Operating Temperature | -55°C ~ 85°C |
| Number of Positions | 100 | Mounting Type | Surface Mount, Right Angle |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Mating Cycles | 20 |
| Material Flammability Rating | UL94 V-0 | Manufacturer Standard Lead Time | 12 Weeks |
| Locking Feature | Flip Lock | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Housing Material | Liquid Crystal Polymer (LCP) | Housing Color | Beige |
| Height Above Board | 0.047" (1.20mm) | Flat Flex Type | FPC |
| Features | Zero Insertion Force (ZIF) | FFC, FCB Thickness | 0.20mm |
| Detailed Description | 100 Position FPC Connector Contacts, Bottom 0.008" (0.20mm) Surface Mount, Right Angle | Current Rating | 0.25A |
| Contact Material | Phosphor Bronze | Contact Finish Thickness | - |
| Contact Finish | Gold | Connector/Contact Type | Contacts, Bottom |
| Cable End Type | Tabbed | Actuator Material | Polyamide (PA), Nylon |
| Actuator Color | Brown |
