M701-230842
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy M701-230842 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy M701-230842 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | M701-230842 |
|---|---|
| Manufacturer | Harwin |
| Description | USB A DOUBLE PC TAIL HORIZ CONN |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | M701-230842 | Manufacturer | Harwin |
|---|---|---|---|
| Description | USB A DOUBLE PC TAIL HORIZ CONN | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 5215 pcs | Data sheet | M701-230842 Drawing |
| Category | Connectors, Interconnects | Voltage - Rated | 30VAC/DC |
| Termination | Solder | Specifications | USB 2.0 |
| Shielding | Unshielded | Shell/Shielding Material | Brass |
| Series | - | Packaging | Bulk |
| Operating Temperature | -55°C ~ 85°C | Number of Ports | 2 |
| Number of Contacts | 8 | Mounting Type | Through Hole, Right Angle |
| Mounting Feature | Horizontal | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Mating Cycles | 1500 | Material Flammability Rating | UL94 V-0 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Insulation Color | White |
| Ingress Protection | - | Gender | Receptacle |
| Features | Board Lock | Detailed Description | USB - A, Stacked USB 2.0 Receptacle Connector 8 Position Through Hole, Right Angle |
| Current Rating | 1.5A | Contact Finish | Gold |
| Connector Type | USB - A, Stacked |
