125GSE
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 125GSE with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 125GSE with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 125GSE |
|---|---|
| Manufacturer | Hammond Manufacturing |
| Description | TRANSFORMER 25W 100HZ-15KHZ |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 5 pcs | 10 pcs | ||
|---|---|---|---|---|---|
| $36.498 | $34.065 | $33.457 | |||
| 25 pcs | 50 pcs | 100 pcs | |||
| $32.848 | $32.362 | $31.632 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | 125GSE | Manufacturer | Hammond Manufacturing |
|---|---|---|---|
| Description | TRANSFORMER 25W 100HZ-15KHZ | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 1126 pcs | Data sheet | 125GSE Drawing125SE Series |
| Category | Transformers | Weight | 6 lbs (2.7kg) |
| Voltage - Isolation | 2000V @ 1 Second | Turns Ratio - Primary:Secondary | - |
| Transformer Type | General Purpose | Termination Style | Solder Lug |
| Size / Dimension | 4.150" L x 2.880" W (105.41mm x 73.15mm) | Series | 125SE |
| Return Loss | - | Power Level | 25W |
| Packaging | Bulk | Other Names | 125GSE-ND HM2523 |
| Operating Temperature | - | Mounting Type | Chassis Mount |
| Moisture Sensitivity Level (MSL) | Not Applicable | Manufacturer Standard Lead Time | 4 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Insertion Loss | - |
| Impedance - Secondary (Ohms) | 4 ~ 32 | Impedance - Primary (Ohms) | 2.5k ~ 10k |
| Height - Seated (Max) | 3.460" (87.88mm) | Frequency Response | ±1dB |
| Frequency Range | 100Hz ~ 15kHz | DC Resistance (DCR) - Secondary | 250 mOhm |
| DC Resistance (DCR) - Primary | 50 Ohm | Approvals | - |
