125ESE
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 125ESE with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 125ESE with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 125ESE |
|---|---|
| Manufacturer | Hammond Manufacturing |
| Description | TRANSFORMER 15W 80MA TUBE SNGL |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $23.182 | $22.408 | $20.862 | $19.317 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 125ESE | Manufacturer | Hammond Manufacturing |
|---|---|---|---|
| Description | TRANSFORMER 15W 80MA TUBE SNGL | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 1982 pcs | Data sheet | 125SE Series125ESE Drawing |
| Category | Transformers | Weight | 3 lbs (1.4kg) |
| Voltage - Isolation | 1500V @ 1 Second | Turns Ratio - Primary:Secondary | - |
| Transformer Type | General Purpose | Termination Style | Wire Leads |
| Size / Dimension | 4.500" L x 2.360" W (114.30mm x 59.94mm) | Series | 125SE |
| Return Loss | - | Power Level | 15W |
| Packaging | Bulk | Other Names | 125ESE-ND HM1475 |
| Operating Temperature | - | Mounting Type | Chassis Mount |
| Manufacturer Standard Lead Time | 4 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insertion Loss | - | Impedance - Secondary (Ohms) | 4 ~ 32 |
| Impedance - Primary (Ohms) | 2.5k ~ 10k | Height - Seated (Max) | 2.940" (74.68mm) |
| Frequency Response | ±1dB | Frequency Range | 100Hz ~ 15kHz |
| DC Resistance (DCR) - Secondary | 590 mOhm | DC Resistance (DCR) - Primary | 100.5 Ohm |
| Approvals | - |
