Home > Products > Circuit Protection > Gas Discharge Tube Arresters (GDT) > PMT809004

PMT809004

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy PMT809004 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	PMT809004
Manufacturer	Hamlin / Littelfuse
Description	GDT 90V 20KA THROUGH HOLE
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 4098 pcs
Reference Price (In US Dollars)	Get a quote

Product parameter
Data sheet

Product parameter

Part Number	PMT809004	Manufacturer	Hamlin / Littelfuse
Description	GDT 90V 20KA THROUGH HOLE	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	4098 pcs	Data sheet	SL1021,24A,B_PMT8 SERIES
Category	Circuit Protection	Voltage - DC Spark Over (Nom)	90V
Tolerance	-	Series	PMT8
Packaging	Tray	Package / Case	Axial Cylinder, 3 Lead (Radial Bend)
Other Names	F5421 PMT809004-ND	Number of Poles	3
Mounting Type	Through Hole	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Impulse Discharge Current (8/20µs)	20000A (20kA)
Fail Short	No	Detailed Description	Gas Discharge Tube 90V 20000A (20kA) 3 Pole Through Hole
