MINISMDC125F/16-2
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy MINISMDC125F/16-2 with confidence from Components-World.HK, 1 Year Warranty
Dowload MINISMDC125F/16-2 Details in PDFSee Product Specifications for product details.
Buy MINISMDC125F/16-2 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | MINISMDC125F/16-2 |
|---|---|
| Manufacturer | Hamlin / Littelfuse |
| Description | PTC RESET FUSE 16V 1.25A 1812 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 5 pcs | 10 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $0.195 | $0.19 | $0.184 | $0.155 | ||
| 100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
| $0.129 | $0.117 | $0.10 | $0.088 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | MINISMDC125F/16-2 | Manufacturer | Hamlin / Littelfuse |
|---|---|---|---|
| Description | PTC RESET FUSE 16V 1.25A 1812 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 242154 pcs | Data sheet | miniSMDC125F/16 SpecPolySwitch, SMD Catalog |
| Category | Circuit Protection | Voltage - Max | 16V |
| Type | Polymeric | Time to Trip | 400ms |
| Thickness (Max) | 0.019" (0.48mm) | Size / Dimension | 0.181" L x 0.128" W (4.60mm x 3.24mm) |
| Series | PolySwitch®, miniSMD | Resistance - Post Trip (R1) (Max) | 140 mOhms |
| Resistance - Initial (Ri) (Min) | 50 mOhms | Ratings | - |
| Packaging | Original-Reel® | Package / Case | 1812 (4532 Metric), Concave |
| Other Names | MINISMDC125F16-2DKR MINISMDC125F162DKR MINISMDC125F162DKR-ND |
Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 2A (4 Weeks) |
| Manufacturer Standard Lead Time | 11 Weeks | Lead Spacing | - |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Height - Seated (Max) | - |
| Detailed Description | Polymeric PTC Resettable Fuse 16V 1.25A Ih Surface Mount 1812 (4532 Metric), Concave | Current - Trip (It) | 2.5A |
| Current - Max | 100A | Current - Hold (Ih) (Max) | 1.25A |
| Approvals | CSA, TUV, UL |
