09350023004
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 09350023004 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 09350023004 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 09350023004 |
|---|---|
| Manufacturer | HARTING |
| Description | CONN MALE PIN 5POS T/H |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $5.021 | $4.566 | $4.451 | $4.109 | ||
| 100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
| $3.881 | $3.538 | $3.31 | $3.036 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 09350023004 | Manufacturer | HARTING |
|---|---|---|---|
| Description | CONN MALE PIN 5POS T/H | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 12501 pcs | Data sheet | 09350023004 Drawing |
| Category | Connectors, Interconnects | Voltage Rating | 690V |
| Termination | Solder | Style | Board to Cable/Wire |
| Shrouding | Shrouded - 4 Wall | Series | Han® PushPull |
| Row Spacing - Mating | - | Pitch - Mating | - |
| Packaging | Bulk | Overall Contact Length | - |
| Other Names | 09350023004-ND 1195-4804 |
Operating Temperature | -40°C ~ 70°C |
| Number of Rows | - | Number of Positions Loaded | All |
| Number of Positions | 5 | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Flammability Rating | UL94 V-0 |
| Mated Stacking Heights | - | Manufacturer Standard Lead Time | 8 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Insulation Material | Thermoplastic |
| Insulation Height | 0.673" (17.10mm) | Insulation Color | Black |
| Ingress Protection | - | Features | Board Lock |
| Fastening Type | Push-Pull | Detailed Description | Connector Header Through Hole 5 position |
| Current Rating | 16A | Contact Type | Male Pin |
| Contact Shape | Circular | Contact Material | - |
| Contact Length - Post | - | Contact Length - Mating | - |
| Contact Finish Thickness - Post | - | Contact Finish Thickness - Mating | - |
| Contact Finish - Post | - | Contact Finish - Mating | - |
| Connector Type | Insert | Applications | - |
