09350023003
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 09350023003 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 09350023003 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 09350023003 |
|---|---|
| Manufacturer | HARTING |
| Description | CONN MALE PIN 5POS T/H R/A |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $5.095 | $4.633 | $4.517 | $4.17 | ||
| 100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
| $3.938 | $3.591 | $3.359 | $3.081 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 09350023003 | Manufacturer | HARTING |
|---|---|---|---|
| Description | CONN MALE PIN 5POS T/H R/A | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 12232 pcs | Data sheet | 09350023003 Drawing |
| Category | Connectors, Interconnects | Voltage Rating | 690V |
| Termination | Solder | Style | Board to Cable/Wire |
| Shrouding | Shrouded - 4 Wall | Series | Han® PushPull |
| Row Spacing - Mating | - | Pitch - Mating | - |
| Packaging | Bulk | Overall Contact Length | - |
| Other Names | 1195-2088 9350023003 |
Operating Temperature | -40°C ~ 70°C |
| Number of Rows | - | Number of Positions Loaded | All |
| Number of Positions | 5 | Mounting Type | Through Hole, Right Angle |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Flammability Rating | UL94 V-0 |
| Mated Stacking Heights | - | Manufacturer Standard Lead Time | 8 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Insulation Material | Thermoplastic |
| Insulation Height | 0.583" (14.80mm) | Insulation Color | Black |
| Ingress Protection | - | Features | Board Lock |
| Fastening Type | Push-Pull | Detailed Description | Connector Header Through Hole, Right Angle 5 position |
| Current Rating | 16A | Contact Type | Male Pin |
| Contact Shape | Circular | Contact Material | - |
| Contact Length - Post | - | Contact Length - Mating | - |
| Contact Finish Thickness - Post | - | Contact Finish Thickness - Mating | - |
| Contact Finish - Post | - | Contact Finish - Mating | - |
| Connector Type | Insert | Applications | - |
