Home > Products > Power Supplies - External/Internal (Off-Board) > LED Drivers > LDB75-024SW

LDB75-024SW

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy LDB75-024SW with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	LDB75-024SW
Manufacturer	Excelsys Technologies Ltd.
Description	LED DRIVER CC/CV AC/DC 12-24V
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 4246 pcs
Reference Price (In US Dollars)	Get a quote

Product parameter
Data sheet

Product parameter

Part Number	LDB75-024SW	Manufacturer	Excelsys Technologies Ltd.
Description	LED DRIVER CC/CV AC/DC 12-24V	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	4246 pcs	Data sheet	LDB75
Category	Power Supplies - External/Internal (Off-Board)	Weight	1.5 lbs (680.4g)
Voltage - Output	12 ~ 24 V	Voltage - Isolation	3.75kV
Voltage - Input (Min)	90VAC	Voltage - Input (Max)	305VAC
Type	Constant Current, Voltage	Topology	AC DC Converter
Termination Style	Wire Leads	Size / Dimension	9.09" L x 1.57" W x 1.12" H (231.0mm x 40.0mm x 28.4mm)
Series	LDB75	Ratings	IP67
Power (Watts)	75W	Other Names	633-1190 LDB75024SW
Operating Temperature	-30°C ~ 70°C	Number of Outputs	1
Mounting Type	Chassis Mount	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Features	OCP, OTP, OVP, SCP
Efficiency	90%	Dimming	-
Detailed Description	3.125A 12 ~ 24 V Constant Current, Voltage LED Driver AC DC Converter Topology 1 Output	Current - Output (Max)	3.125A
Approvals	CE, CSA, cULus, EN
