SQJ415EP-T1_GE3
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy SQJ415EP-T1_GE3 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy SQJ415EP-T1_GE3 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | SQJ415EP-T1_GE3 |
|---|---|
| Manufacturer | Electro-Films (EFI) / Vishay |
| Description | MOSFET P-CHAN 40V POWERPAK SO-8L |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 3000 pcs | ||||
|---|---|---|---|---|---|
| $0.144 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | SQJ415EP-T1_GE3 | Manufacturer | Electro-Films (EFI) / Vishay |
|---|---|---|---|
| Description | MOSFET P-CHAN 40V POWERPAK SO-8L | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 152213 pcs | Data sheet | SQJ415EP |
| Category | Discrete Semiconductor Products | Vgs(th) (Max) @ Id | 2.5V @ 250µA |
| Vgs (Max) | ±20V | Technology | MOSFET (Metal Oxide) |
| Supplier Device Package | PowerPAK® SO-8 | Series | Automotive, AEC-Q101, TrenchFET® |
| Rds On (Max) @ Id, Vgs | 14 mOhm @ 10A, 10V | Power Dissipation (Max) | 45W (Tc) |
| Packaging | Tape & Reel (TR) | Package / Case | 8-PowerTDFN |
| Other Names | SQJ415EP-T1_GE3TR | Operating Temperature | -55°C ~ 175°C (TJ) |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Input Capacitance (Ciss) (Max) @ Vds | 6000pF @ 25V |
| Gate Charge (Qg) (Max) @ Vgs | 95nC @ 10V | FET Type | P-Channel |
| FET Feature | - | Drive Voltage (Max Rds On, Min Rds On) | 4.5V, 10V |
| Drain to Source Voltage (Vdss) | 40V | Detailed Description | P-Channel 40V 30A (Tc) 45W (Tc) Surface Mount PowerPAK® SO-8 |
| Current - Continuous Drain (Id) @ 25°C | 30A (Tc) |
