SIHS20N50C-E3
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy SIHS20N50C-E3 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy SIHS20N50C-E3 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | SIHS20N50C-E3 |
|---|---|
| Manufacturer | Electro-Films (EFI) / Vishay |
| Description | MOSFET N-CH 500V 20A TO-247AD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 500 pcs | ||||
|---|---|---|---|---|---|
| $2.003 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | SIHS20N50C-E3 | Manufacturer | Electro-Films (EFI) / Vishay |
|---|---|---|---|
| Description | MOSFET N-CH 500V 20A TO-247AD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 19231 pcs | Data sheet | SIHS20N50C(-E3) |
| Category | Discrete Semiconductor Products | Vgs(th) (Max) @ Id | 5V @ 250µA |
| Vgs (Max) | ±30V | Technology | MOSFET (Metal Oxide) |
| Supplier Device Package | SUPER-247 (TO-274AA) | Series | - |
| Rds On (Max) @ Id, Vgs | 270 mOhm @ 10A, 10V | Power Dissipation (Max) | 250mW (Tc) |
| Packaging | Tube | Package / Case | TO-274AA |
| Operating Temperature | -55°C ~ 150°C (TJ) | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 18 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Input Capacitance (Ciss) (Max) @ Vds | 2942pF @ 25V |
| Gate Charge (Qg) (Max) @ Vgs | 76nC @ 10V | FET Type | N-Channel |
| FET Feature | - | Drive Voltage (Max Rds On, Min Rds On) | 10V |
| Drain to Source Voltage (Vdss) | 500V | Detailed Description | N-Channel 500V 20A (Tc) 250mW (Tc) Through Hole SUPER-247 (TO-274AA) |
| Current - Continuous Drain (Id) @ 25°C | 20A (Tc) |
