B65803J0000R097
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy B65803J0000R097 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy B65803J0000R097 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | B65803J0000R097 |
|---|---|
| Manufacturer | EPCOS |
| Description | FERRITE CORE RM 1.1UH N97 2PCS |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1200 pcs | ||||
|---|---|---|---|---|---|
| $0.258 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | B65803J0000R097 | Manufacturer | EPCOS |
|---|---|---|---|
| Description | FERRITE CORE RM 1.1UH N97 2PCS | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 85370 pcs | Data sheet | B65803,04,06, B65539 Series Datasheet |
| Category | Magnetics - Transformer, Inductor Components | Width | 4.60mm |
| Tolerance | -20%, +30% | Supplier Device Package | RM 4 |
| Series | B65803 | Other Names | B65803J R 97 B65803JR97 B65803JR97-ND |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Minimum Core Cross Section (Amin) mm² | 11.3 |
| Material | N97 | Manufacturer Standard Lead Time | 27 Weeks |
| Length | 11.00mm | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Initial Permeability (µi) | 2300 | Inductance Factor (Al) | 1.1µH |
| Height | 5.25mm | Gap | Ungapped |
| Finish | Uncoated | Effective Permeability (µe) | 1480 |
| Effective Magnetic Volume (Ve) mm³ | 286 | Effective Length (le) mm | 22 |
| Effective Area (Ae) mm² | 13 | Diameter | - |
| Core Type | RM | Core Factor (ΣI/A) mm1 | 1.7 |
