Home > Products > Magnetics - Transformer, Inductor Components > Ferrite Cores > B65671T0100A033

B65671T0100A033

B65671T0100A033

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy B65671T0100A033 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	B65671T0100A033
Manufacturer	EPCOS
Description	FERRITE CORE P 100NH M33 2PCS
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

	100 pcs	250 pcs	500 pcs	1000 pcs
~~In Stock~~ 34595 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	25 pcs	50 pcs
	$2.375	$2.023	$1.54	$1.496
	$1.32	$1.232	$1.144	$1.10

Product parameter
Data sheet

Product parameter

Part Number	B65671T0100A033	Manufacturer	EPCOS
Description	FERRITE CORE P 100NH M33 2PCS	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	34595 pcs	Data sheet	B65671/2/5/9 Datasheet
Category	Magnetics - Transformer, Inductor Components	Width	-
Tolerance	±3%	Supplier Device Package	P 26 x 16
Series	B65671	Other Names	495-5809 B65671T 100A 33 B65671T0100A033-ND B65671T100A33 Q7062078
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Minimum Core Cross Section (Amin) mm²	76.5
Material	M33	Manufacturer Standard Lead Time	24 Weeks
Length	-	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Initial Permeability (µi)	750	Inductance Factor (Al)	100nH
Height	8.15mm	Gap	Gapped
Finish	Uncoated	Effective Permeability (µe)	32
Effective Magnetic Volume (Ve) mm³	3460	Effective Length (le) mm	37.2
Effective Area (Ae) mm²	93	Diameter	26.00mm
Core Type	P (Pot Core)	Core Factor (ΣI/A) mm1	0.4
