B65541T0100A033
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy B65541T0100A033 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy B65541T0100A033 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | B65541T0100A033 |
|---|---|
| Manufacturer | EPCOS |
| Description | FERRITE CORE P 100NH M33 2PCS |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $1.074 | $0.92 | $0.69 | $0.671 | ||
| 100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
| $0.594 | $0.556 | $0.517 | $0.479 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | B65541T0100A033 | Manufacturer | EPCOS |
|---|---|---|---|
| Description | FERRITE CORE P 100NH M33 2PCS | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 77612 pcs | Data sheet | B6554x Series |
| Category | Magnetics - Transformer, Inductor Components | Width | - |
| Tolerance | ±3% | Supplier Device Package | P 14 x 8 |
| Series | B65541 | Other Names | 495-5126 B65541T 100A 33 B65541T100A33 B65541T100A33-ND |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Minimum Core Cross Section (Amin) mm² | 20 |
| Material | M33 | Manufacturer Standard Lead Time | 47 Weeks |
| Length | - | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Initial Permeability (µi) | 750 | Inductance Factor (Al) | 100nH |
| Height | 4.25mm | Gap | Gapped |
| Finish | Uncoated | Effective Permeability (µe) | 64 |
| Effective Magnetic Volume (Ve) mm³ | 500 | Effective Length (le) mm | 20 |
| Effective Area (Ae) mm² | 25 | Diameter | 14.30mm |
| Core Type | P (Pot Core) | Core Factor (ΣI/A) mm1 | 0.8 |
