Home > Products > Magnetics - Transformer, Inductor Components > Ferrite Cores > B64290L0045X830

B64290L0045X830

B64290L0045X830

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy B64290L0045X830 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	B64290L0045X830
Manufacturer	EPCOS
Description	FERRITE CORE TOROID 2.77UH N30
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

	250 pcs	500 pcs	1000 pcs	5000 pcs
~~In Stock~~ 258135 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	25 pcs	50 pcs	100 pcs
	$0.224	$0.184	$0.159	$0.143	$0.127
	$0.114	$0.105	$0.089	$0.082

Product parameter
Data sheet

Product parameter

Part Number	B64290L0045X830	Manufacturer	EPCOS
Description	FERRITE CORE TOROID 2.77UH N30	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	258135 pcs	Data sheet	B64290L0045 Datasheet Ferrites, Accessories General Info
Category	Magnetics - Transformer, Inductor Components	Width	-
Tolerance	±25%	Supplier Device Package	-
Series	B64290	Other Names	495-3855 B64290L 45X830 B64290L 45X830 B64290L45X830
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Material	N30
Manufacturer Standard Lead Time	31 Weeks	Length	-
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Initial Permeability (µi)	4300
Inductance Factor (Al)	2.77µH	Height	7.30mm
Gap	Ungapped	Finish	Epoxy
Effective Magnetic Volume (Ve) mm³	760	Effective Length (le) mm	38.52
Effective Area (Ae) mm²	19.73	Diameter	17.20mm
Core Type	Toroid	Core Factor (ΣI/A) mm1	1.95
