Home > Products > Switches > Tactile Switches > TL3300AF160Q

TL3300AF160Q

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy TL3300AF160Q with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	TL3300AF160Q
Manufacturer	E-Switch
Description	SWITCH TACTILE SPST-NO 0.05A 12V
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 195310 pcs
Reference Price (In US Dollars)	500 pcs	1000 pcs	5000 pcs
Reference Price (In US Dollars)	$0.152	$0.12	$0.112

Product parameter
Data sheet

Product parameter

Part Number	TL3300AF160Q	Manufacturer	E-Switch
Description	SWITCH TACTILE SPST-NO 0.05A 12V	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	195310 pcs	Data sheet	TL3300AF160Q Drawing TL3300 Series Datasheet
Category	Switches	Termination Style	Gull Wing
Switch Travel	0.35mm	Switch Function	Off-Mom
Series	TL3300	Packaging	Tape & Reel (TR)
Outline	12.00mm x 12.00mm	Other Names	EG4902TR
Operating Temperature	-25°C ~ 70°C	Operating Force	160gf
Mounting Type	Surface Mount	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Mechanical Life	200,000 Cycles	Manufacturer Standard Lead Time	11 Weeks
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Ingress Protection	-
Illumination Voltage (Nominal)	-	Illumination Type, Color	-
Illumination	Non-Illuminated	Features	-
Detailed Description	Tactile Switch SPST-NO Top Actuated Surface Mount	Contact Rating @ Voltage	0.05A @ 12VDC
Circuit	SPST-NO	Actuator Type	Plunger for Cap
Actuator Orientation	Top Actuated	Actuator Material	-
Actuator Length, Right Angle	-	Actuator Height off PCB, Vertical	7.30mm
