Home > Products > Switches > Rocker Switches > RB242D1021-136/ACC-F02-1

RB242D1021-136/ACC-F02-1

RB242D1021-136/ACC-F02-1

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy RB242D1021-136/ACC-F02-1 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	RB242D1021-136/ACC-F02-1
Manufacturer	E-Switch
Description	SWITCH ROCKER DPST 20A 125V
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 4835 pcs
Reference Price (In US Dollars)	Get a quote

Product parameter
Data sheet

Product parameter

Part Number	RB242D1021-136/ACC-F02-1	Manufacturer	E-Switch
Description	SWITCH ROCKER DPST 20A 125V	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	4835 pcs	Data sheet	RB242D1021-136/ACC-F02-1 Drawing RB2 Series Datasheet
Category	Switches	Voltage Rating - AC	125V
Termination Style	Quick Connect - 0.250" (6.3mm)	Switch Function	On-Off
Series	RB2, LAMB	Panel Cutout Dimensions	Rectangular - 30.00mm x 22.00mm
Packaging	Bulk	Other Names	RB242D1021136/ACCF021
Operating Temperature	-20°C ~ 65°C	Mounting Type	Panel Mount, Snap-In
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Mechanical Life	-
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Ingress Protection	IP54 - Dust Protected, Water Resistant
Illumination Voltage (Nominal)	125 VAC	Illumination Type, Color	Neon, Green
Features	Sealing Boot	Electrical Life	10,000 Cycles
Detailed Description	Rocker Switch DPST 20A (AC) 125V Panel Mount, Snap-In	Current Rating	20A (AC)
Color - Actuator/Cap	Green	Circuit	DPST
Actuator Type	Concave (Curved) - Illuminated	Actuator Marking	O -
