Home > Products > Integrated Circuits (ICs) > PMIC - LED Drivers > AP3009KTR-E1

AP3009KTR-E1

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy AP3009KTR-E1 with confidence from Components-World.HK, 1 Year Warranty

Dowload AP3009KTR-E1 Details in PDF

Request a Quote

Part Number	AP3009KTR-E1
Manufacturer	Diodes Incorporated
Description	IC LED DRIVER RGLTR DIM
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 5603 pcs
Reference Price (In US Dollars)	Get a quote

Product parameter
Data sheet

Product parameter

Part Number	AP3009KTR-E1	Manufacturer	Diodes Incorporated
Description	IC LED DRIVER RGLTR DIM	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	5603 pcs	Data sheet	AP3009
Category	Integrated Circuits (ICs)	Voltage - Supply (Min)	2.5V
Voltage - Supply (Max)	16V	Voltage - Output	38V
Type	DC DC Regulator	Topology	Step-Up (Boost)
Supplier Device Package	SOT-23-6	Series	-
Packaging	Tape & Reel (TR)	Package / Case	SOT-23-6
Operating Temperature	-40°C ~ 85°C (TA)	Number of Outputs	1
Mounting Type	Surface Mount	Moisture Sensitivity Level (MSL)	3 (168 Hours)
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Internal Switch(s)	Yes
Frequency	1.2MHz	Dimming	Analog
Detailed Description	LED Driver IC 1 Output DC DC Regulator Step-Up (Boost) Analog Dimming 560mA (Switch) SOT-23-6	Current - Output / Channel	560mA (Switch)
Applications	Backlight
