TS2P5M20
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy TS2P5M20 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy TS2P5M20 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | TS2P5M20 |
|---|---|
| Manufacturer | Conxall / Switchcraft |
| Description | CONN RCPT MALE 5POS GOLD |
| Lead Free Status / RoHS Status |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $6.086 | $5.652 | $5.072 | $4.927 | ||
| 100 pcs | 250 pcs | 500 pcs | |||
| $4.348 | $4.058 | $3.971 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | TS2P5M20 | Manufacturer | Conxall / Switchcraft |
|---|---|---|---|
| Description | CONN RCPT MALE 5POS GOLD | Lead Free Status / RoHS Status | |
| Quantity Available | 9647 pcs | Data sheet | TS Series BulletinTS2P Series Drawing |
| Category | Connectors, Interconnects | Voltage Rating | 125VAC/DC |
| Termination | Crimp or Solder Cup | Shielding | Shielded |
| Shell Size, MIL | - | Shell Size - Insert | - |
| Shell Material | Copper Alloy | Shell Finish | Electroless Nickel |
| Series | Dura-Twist™, TS | Packaging | Bulk |
| Other Names | SC2621 | Orientation | Keyed |
| Operating Temperature | -40°C ~ 135°C | Number of Positions | 5 |
| Mounting Type | Panel Mount | Mounting Feature | Bulkhead - Rear Side Nut |
| Material Flammability Rating | - | Manufacturer Standard Lead Time | 12 Weeks |
| Insert Material | Liquid Crystal Polymer (LCP) | Ingress Protection | IP66/67/68 - Dust Tight, Water Resistant, Waterproof |
| Features | - | Fastening Type | Threaded |
| Detailed Description | 5 Position Circular Connector Receptacle, Male Pins Crimp or Solder Cup Gold | Current Rating | - |
| Contact Material | Copper Alloy | Contact Finish Thickness - Mating | - |
| Contact Finish - Mating | Gold | Connector Type | Receptacle, Male Pins |
| Color | Silver | Cable Opening | - |
| Backshell Material, Plating | - | Applications | Agriculture, Audio, General, Medical, Testing Equipment & Measurement |
