RAPC752SX
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy RAPC752SX with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy RAPC752SX with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | RAPC752SX |
|---|---|
| Manufacturer | Conxall / Switchcraft |
| Description | CONN PWR JACK 0.7X2.35MM SOLDER |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $0.466 | $0.429 | $0.404 | $0.392 | ||
| 100 pcs | 250 pcs | 500 pcs | |||
| $0.374 | $0.368 | $0.36 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | RAPC752SX | Manufacturer | Conxall / Switchcraft |
|---|---|---|---|
| Description | CONN PWR JACK 0.7X2.35MM SOLDER | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 101842 pcs | Data sheet | Jack SchematicsRAPC752SX Drawing |
| Category | Connectors, Interconnects | Voltage - Rated | - |
| Thread Size | - | Termination | Solder |
| Shielding | Shielded | Series | - |
| Packaging | - | Other Names | RAPC752S RAPC752S-ND RAPC752SX-ND SC1864 |
| Operating Temperature | - | Number of Positions/Contacts | 2 Conductors, 3 Contacts |
| Mounting Type | Through Hole, Right Angle | Mounting Feature | - |
| Mating Length/Depth | - | Material Flammability Rating | - |
| Manufacturer Standard Lead Time | 12 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Internal Switch(s) | Single Switch, Normally Closed | Insulation Color | - |
| Ingress Protection | - | Industry Recognized Mating Diameter | 0.70mm ID (0.028"), 2.35mm OD (0.093") EIAJ-1 |
| Includes | - | Housing Material | Thermoplastic |
| Gender | Male | Features | - |
| Detailed Description | Power Barrel Connector Jack 0.70mm ID (0.028"), 2.35mm OD (0.093") EIAJ-1 Through Hole, Right Angle | Current Rating | 3A |
| Contact Material - Plating | Silver | Contact Material | Copper Alloy |
| Connector Type | Jack | Body Material | - |
| Body Color | Black | Actual Diameter | 0.026" (0.65mm ID), 0.108" (2.75mm OD) |
