RA49B14B
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy RA49B14B with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy RA49B14B with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | RA49B14B |
|---|---|
| Manufacturer | Conxall / Switchcraft |
| Description | CONN JACK STEREO 6.35MM R/A |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | ||
|---|---|---|---|---|---|
| $1.178 | $0.952 | $0.873 | |||
| 50 pcs | 100 pcs | 250 pcs | |||
| $0.833 | $0.793 | $0.775 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | RA49B14B | Manufacturer | Conxall / Switchcraft |
|---|---|---|---|
| Description | CONN JACK STEREO 6.35MM R/A | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 42075 pcs | Data sheet | RA49B Series Drawing |
| Category | Connectors, Interconnects | Voltage - Rated | - |
| Thread Size | 3/8"-32 | Termination | Solder |
| Signal Lines | Stereo (3 Conductor, TRS) | Shielding | Unshielded |
| Series | RA Jax® | Panel Hole Size | - |
| Packaging | Bulk | Other Names | RA49B14B-ND SC2030 |
| Operating Temperature | - | Number of Positions/Contacts | 3 Conductors, 5 Contacts |
| Mounting Type | Through Hole, Right Angle | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Mating Length/Depth | - | Manufacturer Standard Lead Time | 12 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Internal Switch(s) | Two Switches |
| Insulation Color | - | Industry Recognized Mating Diameter | 6.35mm (0.250", 1/4") - Headphone |
| Includes | 3 pcs - 1 Connector, 1 Nut, 1 Washer | Housing Material | Thermoplastic, Polyester |
| Gender | Female | Features | Board Guide |
| Detailed Description | 6.35mm (0.250", 1/4") - Headphone Phone Jack Stereo (3 Conductor, TRS) Connector Solder | Contact Material - Plating | Silver |
| Contact Material | Copper Alloy | Connector Type | Phone Jack |
| Cable Opening | - | Body Material | - |
| Body Color | Black | Actual Diameter | 0.253" (6.43mm) |
