CL-505S-X-SD-T
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy CL-505S-X-SD-T with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy CL-505S-X-SD-T with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | CL-505S-X-SD-T |
|---|---|
| Manufacturer | Citizen Electronics Co., Ltd. |
| Description | LED TRI TOP FIRING 1.0 X 1.0 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 5000 pcs | 10000 pcs | 25000 pcs | ||
|---|---|---|---|---|---|
| $0.085 | $0.084 | $0.082 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | CL-505S-X-SD-T | Manufacturer | Citizen Electronics Co., Ltd. |
|---|---|---|---|
| Description | LED TRI TOP FIRING 1.0 X 1.0 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 294262 pcs | Data sheet | CL-505S Series |
| Category | Optoelectronics | Wavelength - Peak | - |
| Wavelength - Dominant | 615nm Red, 530nm Green, 470nm Blue | Voltage - Forward (Vf) (Typ) | 1.85V Red, 2.7V Green, 2.75V Blue |
| Viewing Angle | - | Supplier Device Package | - |
| Size / Dimension | 1.00mm L x 1.00mm W | Series | CL-505S |
| Packaging | Tape & Reel (TR) | Package / Case | 0404 (1010 Metric) |
| Other Names | 1642-1510-2 CL-505S-X-SD |
Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | Millicandela Rating | 40mcd Red, 220mcd Green, 65mcd Blue |
| Manufacturer Standard Lead Time | 8 Weeks | Lens Transparency | - |
| Lens Style/Size | Square with Flat Top, 1.00mm | Lens Color | - |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Height (Max) | 0.26mm |
| Features | - | Detailed Description | Red, Green, Blue (RGB) 615nm Red, 530nm Green, 470nm Blue LED Indication - Discrete 1.85V Red, 2.7V Green, 2.75V Blue 0404 (1010 Metric) |
| Current - Test | 5mA Red, 5mA Green, 5mA Blue | Configuration | Common Anode |
| Color | Red, Green, Blue (RGB) |
