Home > Products > Switches > Rocker Switches > LRA32H2DBBNN

LRA32H2DBBNN

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy LRA32H2DBBNN with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	LRA32H2DBBNN
Manufacturer	Cherry Switches (ZF Electronics)
Description	SWITCH ROCKER DPST 10A 125V
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

	250 pcs	500 pcs	1000 pcs	5000 pcs
~~In Stock~~ 80915 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	25 pcs	50 pcs	100 pcs
	$0.447	$0.41	$0.392	$0.374	$0.356
	$0.347	$0.338	$0.285	$0.276

Product parameter
Data sheet

Product parameter

Part Number	LRA32H2DBBNN	Manufacturer	Cherry Switches (ZF Electronics)
Description	SWITCH ROCKER DPST 10A 125V	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	80915 pcs	Data sheet	LR Series Datasheet
Category	Switches	Voltage Rating - AC	125V
Termination Style	Quick Connect - 0.187" (4.7mm)	Switch Function	On-Off
Series	LR	Panel Cutout Dimensions	Rectangular - 19.10mm x 12.90mm
Packaging	Bulk	Other Names	CH771
Operating Temperature	-20°C ~ 65°C	Mounting Type	Panel Mount, Snap-In
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Mechanical Life	100,000 Cycles
Manufacturer Standard Lead Time	18 Weeks	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Ingress Protection	-	Illumination Voltage (Nominal)	-
Illumination Type, Color	-	Features	-
Electrical Life	6,000 Cycles	Detailed Description	Rocker Switch DPST 10A (AC) 125V Panel Mount, Snap-In
Current Rating	10A (AC)	Color - Actuator/Cap	Black
Circuit	DPST	Actuator Type	Concave (Curved)
Actuator Marking	On - Off, Vertical
