Home > Products > Switches > Snap Action, Limit Switches > E14-00M

E14-00M

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy E14-00M with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	E14-00M
Manufacturer	Cherry Switches (ZF Electronics)
Description	SWITCH SNAP ACTION SPDT 25A 125V
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 25593 pcs
Reference Price (In US Dollars)	1000 pcs
Reference Price (In US Dollars)	$1.543

Product parameter
Data sheet

Product parameter

Part Number	E14-00M	Manufacturer	Cherry Switches (ZF Electronics)
Description	SWITCH SNAP ACTION SPDT 25A 125V	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	25593 pcs	Data sheet	E13,14, G13 Series Datasheet
Category	Switches	Voltage Rating - DC	48V
Voltage Rating - AC	125V	Termination Style	Quick Connect - 0.250" (6.3mm)
Switch Function	On-Mom	Series	E
Release Force	-	Pretravel	0.100" (2.5mm)
Packaging	Bulk	Overtravel	0.168" (4.3mm)
Other Names	0E14-00M 0E14-00M0 0E1400M0 0E1400MO CH318 E14-00M0	Operating Temperature	-40°C ~ 105°C
Operating Position	0.776" (19.7mm)	Operating Force	850gf
Mounting Type	Panel Mount	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Mechanical Life	-	Manufacturer Standard Lead Time	18 Weeks
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Ingress Protection	-
Features	-	Electrical Life	6,000 Cycles
Differential Travel	0.015" (0.38mm)	Current Rating	25A (AC), 2A (DC)
Circuit	SPDT	Actuator Type	Overtravel Plunger
