PCN2-S5-S12-S
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy PCN2-S5-S12-S with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy PCN2-S5-S12-S with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | PCN2-S5-S12-S |
|---|---|
| Manufacturer | CUI Inc. |
| Description | DC/DC CONVERTER 12V 2W |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 5 pcs | 10 pcs | 25 pcs | |
|---|---|---|---|---|---|
| $2.077 | $2.048 | $2.018 | $1.958 | ||
| 50 pcs | 100 pcs | 250 pcs | 500 pcs | ||
| $1.899 | $1.84 | $1.78 | $1.662 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | PCN2-S5-S12-S | Manufacturer | CUI Inc. |
|---|---|---|---|
| Description | DC/DC CONVERTER 12V 2W | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 20503 pcs | Data sheet | PCN2-S Datasheet |
| Category | Power Supplies - Board Mount | Voltage - Working | 2W |
| Voltage - Output 4 | - | Voltage - Output 3 | - |
| Voltage - Output 2 | 12V | Voltage - Input (Max) | 5.5V |
| Voltage - Dropout (Typical) | 4.5V | Type | Isolated Module |
| Size / Dimension | 0.77" L x 0.28" W x 0.40" H (19.6mm x 7.2mm x 10.2mm) | Series | PCN2-S |
| RoHS Status | Tube | Ripple Current - Low Frequency | ITE (Commercial) |
| Polarization | 6-SIP Module, 4 Leads | Output Configuration | 1 |
| Other Names | 102-3929 | Operating Temperature | -40°C ~ 100°C |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 13 Weeks | Manufacturer Part Number | PCN2-S5-S12-S |
| Line Regulation | 86% | Features | SCP |
| Feature Pins | 167mA | Expanded Description | Isolated Module DC DC Converter 1 Output 12V 167mA 4.5V - 5.5V Input |
| Description | DC/DC CONVERTER 12V 2W | Current - Breakover | 1kV (1000V) |
