PCN2-S5-D15-S
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy PCN2-S5-D15-S with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy PCN2-S5-D15-S with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | PCN2-S5-D15-S |
|---|---|
| Manufacturer | CUI, Inc. |
| Description | DC DC CONVERTER +/-15V 2W |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 5 pcs | 14 pcs | 28 pcs | |
|---|---|---|---|---|---|
| $2.118 | $2.086 | $2.056 | $1.995 | ||
| 56 pcs | 112 pcs | 252 pcs | 504 pcs | ||
| $1.935 | $1.874 | $1.814 | $1.693 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | PCN2-S5-D15-S | Manufacturer | CUI, Inc. |
|---|---|---|---|
| Description | DC DC CONVERTER +/-15V 2W | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 22203 pcs | Data sheet | PCN2-S Datasheet |
| Category | Power Supplies - Board Mount | Voltage - Output 3 | - |
| Voltage - Output 2 | -15V | Voltage - Output 1 | 15V |
| Voltage - Isolation | 1kV | Voltage - Input (Min) | 4.5V |
| Voltage - Input (Max) | 5.5V | Type | Isolated Module |
| Size / Dimension | 0.77" L x 0.28" W x 0.40" H (19.6mm x 7.2mm x 10.2mm) | Series | PCN2-S |
| Power (Watts) | 2W | Packaging | Tube |
| Package / Case | 6-SIP Module, 5 Leads | Other Names | 102-3932 |
| Operating Temperature | -40°C ~ 100°C | Number of Outputs | 2 |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | Not Applicable |
| Manufacturer Standard Lead Time | 12 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Features | SCP | Efficiency | 86% |
| Detailed Description | Isolated Module DC DC Converter 2 Output 15V -15V 67mA, 67mA 4.5V - 5.5V Input | Current - Output (Max) | 67mA, 67mA |
| California Prop 65 | Warning Information WARNING: Cancer and Reproductive Harm - www.P65warnings.ca.gov. | Applications | ITE (Commercial) |
