Home > Products > Switches > Slide Switches > OS203012MU5QP1

OS203012MU5QP1

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy OS203012MU5QP1 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	OS203012MU5QP1
Manufacturer	C&K
Description	SWITCH SLIDE DP3T 100MA 30V
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

	250 pcs	500 pcs	1000 pcs	5000 pcs
~~In Stock~~ 132082 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	25 pcs	50 pcs	100 pcs
	$0.268	$0.258	$0.253	$0.226	$0.215
	$0.21	$0.178	$0.172	$0.151

Product parameter
Data sheet

Product parameter

Part Number	OS203012MU5QP1	Manufacturer	C&K
Description	SWITCH SLIDE DP3T 100MA 30V	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	132082 pcs	Data sheet	OS Series Slide Datasheet
Category	Switches	Voltage Rating - DC	30V
Termination Style	PC Pin	Switch Travel	2.50mm
Switch Function	On-On-On	Series	OS
Packaging	Bulk	Other Names	*OS203012MU5QP1 CKN9554
Operating Temperature	-30°C ~ 70°C	Operating Force	-
Mounting Type	Through Hole	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Mechanical Life	10,000 Cycles	Manufacturer Standard Lead Time	24 Weeks
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Features	Epoxy Sealed Terminals
Electrical Life	10,000 Cycles	Detailed Description	Slide Switch DP3T Through Hole
Current Rating	100mA (DC)	Contact Timing	Not Specified
Contact Material	Copper Alloy	Contact Finish	Silver
Circuit	DP3T	Actuator Type	Standard
Actuator Material	Polyoxymethylene (Acetal) (POM)	Actuator Length	4.00mm
