PQ2614BLA-4R7K
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy PQ2614BLA-4R7K with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy PQ2614BLA-4R7K with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | PQ2614BLA-4R7K |
|---|---|
| Manufacturer | Bourns, Inc. |
| Description | FIXED IND 4.7UH 30A 1.6MOHM SMD |
| Lead Free Status / RoHS Status | RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 25 pcs | 100 pcs | ||
|---|---|---|---|---|---|
| $1.328 | $1.105 | $0.796 | |||
| 500 pcs | 1000 pcs | 2500 pcs | |||
| $0.707 | $0.663 | $0.641 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | PQ2614BLA-4R7K | Manufacturer | Bourns, Inc. |
|---|---|---|---|
| Description | FIXED IND 4.7UH 30A 1.6MOHM SMD | Lead Free Status / RoHS Status | RoHS Compliant |
| Quantity Available | 50575 pcs | Data sheet | PQ2614BHA,BHA Series |
| Category | Inductors, Coils, Chokes | Type | Wirewound |
| Tolerance | ±10% | Supplier Device Package | - |
| Size / Dimension | 1.098" L x 0.780" W (27.90mm x 19.80mm) | Shielding | Shielded |
| Series | PQ2614BLA | RoHS Status | RoHS Compliant |
| Ratings | AEC-Q200 | Q @ Freq | - |
| Packaging | Tray | Package / Case | Nonstandard |
| Operating Temperature | -40°C ~ 155°C | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material - Core | Ferrite |
| Manufacturer Standard Lead Time | 13 Weeks | Inductance Frequency - Test | 100kHz |
| Inductance | 4.7µH | Height - Seated (Max) | 0.630" (16.00mm) |
| Frequency - Self Resonant | 30MHz | Features | - |
| Detailed Description | 4.7µH Shielded Wirewound Inductor 30A 1.6 mOhm Max Nonstandard | DC Resistance (DCR) | 1.6 mOhm Max |
| Current Rating | 30A | Current - Saturation | 36.9A |
