70F504AI-RC
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 70F504AI-RC with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 70F504AI-RC with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 70F504AI-RC |
|---|---|
| Manufacturer | Bourns, Inc. |
| Description | FIXED IND 500UH 91MA 18 OHM TH |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | 70F504AI-RC | Manufacturer | Bourns, Inc. |
|---|---|---|---|
| Description | FIXED IND 500UH 91MA 18 OHM TH | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 3964 pcs | Data sheet | 70F Series |
| Category | Inductors, Coils, Chokes | Type | Wirewound |
| Tolerance | ±5% | Supplier Device Package | Axial |
| Size / Dimension | 0.190" Dia x 0.250" L (4.83mm x 6.35mm) | Shielding | Unshielded |
| Series | 70F | Ratings | - |
| Q @ Freq | 49 @ 790kHz | Packaging | Bulk |
| Package / Case | Axial | Other Names | 70F504AIRC |
| Operating Temperature | -55°C ~ 105°C | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material - Core | Iron |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Inductance Frequency - Test | 790kHz |
| Inductance | 500µH | Height - Seated (Max) | - |
| Frequency - Self Resonant | 1.8MHz | Detailed Description | 500µH Unshielded Wirewound Inductor 91mA 18 Ohm Max Axial |
| DC Resistance (DCR) | 18 Ohm Max | Current Rating | 91mA |
| Current - Saturation | - |
