3309505
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 3309505 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 3309505 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 3309505 |
|---|---|
| Manufacturer | Bomar (Winchester Electronics) |
| Description | CONN ADAPT BNC PLUG TO SMA PLUG |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | 3309505 | Manufacturer | Bomar (Winchester Electronics) |
|---|---|---|---|
| Description | CONN ADAPT BNC PLUG TO SMA PLUG | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 5336 pcs | Data sheet | Between Series Adapters |
| Category | Connectors, Interconnects | Style | Straight |
| Series | - | Packaging | Bulk |
| Other Names | 991-1082 | Operating Temperature | -55°C ~ 100°C |
| Mounting Type | Free Hanging (In-Line) | Mounting Feature | - |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Mating Cycles | - |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Insertion Loss | - |
| Ingress Protection | - | Includes | - |
| Impedance | 50 Ohm | Frequency - Max | 1GHz |
| Features | - | Fastening Type | Bayonet Lock, Threaded |
| Dielectric Material | - | Detailed Description | Adapter Coaxial Connector BNC Plug, Male Pin To SMA Plug, Male Pin 50 Ohm |
| Convert To (Adapter End) | SMA Plug, Male Pin | Convert From (Adapter End) | BNC Plug, Male Pin |
| Conversion Type | Between Series | Center Gender | Male to Male |
| Center Contact Plating | Gold | Center Contact Material | Brass |
| Body Material | Brass | Body Finish | Nickel |
| Adapter Type | Plug to Plug | Adapter Series | BNC to SMA |
