Home > Products > Boxes, Enclosures, Racks > Backplanes > 23001010

23001010

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 23001010 with confidence from Components-World.HK, 1 Year Warranty

Dowload 23001010 Details in PDF

Request a Quote

Part Number	23001010
Manufacturer	Birtcher / Pentair
Description	BACKPLANE VME J1 10SLOT 3U
Lead Free Status / RoHS Status	Lead free by exemption / RoHS Compliant

~~In Stock~~ 263 pcs
Reference Price (In US Dollars)	1 pcs
Reference Price (In US Dollars)	$143.797

Product parameter
Data sheet

Product parameter

Part Number	23001010	Manufacturer	Birtcher / Pentair
Description	BACKPLANE VME J1 10SLOT 3U	Lead Free Status / RoHS Status	Lead free by exemption / RoHS Compliant
Quantity Available	263 pcs	Data sheet	VME, VME64x Backplanes User Manual
Category	Boxes, Enclosures, Racks	Series	VMEbus
Panel Units	3U	Other Names	1439-1383 23001-010
Number of Channels	10	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Manufacturer Standard Lead Time	8 Weeks	Lead Free Status / RoHS Status	Lead free by exemption / RoHS Compliant
Interface	VME J1	Detailed Description	Backplane 3U 10 Channel VME J1 0.800" (20.32mm) Connector Spacing
Connector Spacing	0.800" (20.32mm)
