VNA515
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy VNA515 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy VNA515 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | VNA515 |
|---|---|
| Manufacturer | Bel |
| Description | CONN ADAPT JACK-JACK N 50 OHM |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $2.991 | $2.862 | $2.602 | $2.472 | ||
| 100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
| $2.407 | $2.147 | $2.017 | $1.782 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | VNA515 | Manufacturer | Bel |
|---|---|---|---|
| Description | CONN ADAPT JACK-JACK N 50 OHM | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 17922 pcs | Data sheet | VNA515 Drawing |
| Category | Connectors, Interconnects | Style | Straight |
| Series | - | Packaging | Bulk |
| Other Names | 1427-1082 | Operating Temperature | -65°C ~ 165°C |
| Mounting Type | Free Hanging (In-Line) | Mounting Feature | - |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Mating Cycles | 500 |
| Manufacturer Standard Lead Time | 6 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insertion Loss | - | Ingress Protection | - |
| Includes | - | Impedance | 50 Ohm |
| Frequency - Max | 11GHz | Features | - |
| Fastening Type | Threaded, Threaded | Dielectric Material | Polytetrafluoroethylene (PTFE) |
| Detailed Description | Adapter Coaxial Connector N Jack, Female Socket To N Jack, Female Socket 50 Ohm | Convert To (Adapter End) | N Jack, Female Socket |
| Convert From (Adapter End) | N Jack, Female Socket | Conversion Type | Same Series |
| Center Gender | Female to Female | Center Contact Plating | Gold |
| Center Contact Material | Brass | Body Material | Brass |
| Body Finish | Nickel | Adapter Type | Jack to Jack |
| Adapter Series | N to N |
