DSP1N5D14
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy DSP1N5D14 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy DSP1N5D14 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | DSP1N5D14 |
|---|---|
| Manufacturer | Bel |
| Description | DC DC CONVERTER +/-14V 1W |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | DSP1N5D14 | Manufacturer | Bel |
|---|---|---|---|
| Description | DC DC CONVERTER +/-14V 1W | Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Quantity Available | 4683 pcs | Data sheet | DSP1 Dual-Output |
| Category | Power Supplies - Board Mount | Voltage - Output 3 | - |
| Voltage - Output 2 | -14V | Voltage - Output 1 | 14V |
| Voltage - Isolation | 700V | Voltage - Input (Min) | 4.5V |
| Voltage - Input (Max) | 5.5V | Type | Isolated Module |
| Size / Dimension | 0.77" L x 0.27" W x 0.40" H (19.6mm x 6.9mm x 10.2mm) | Series | DSP1 |
| Power (Watts) | 1W | Packaging | Bulk |
| Package / Case | 5-SIP Module | Other Names | 179-1077 |
| Operating Temperature | -40°C ~ 85°C | Number of Outputs | 2 |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | Features | - |
| Efficiency | 70% | Detailed Description | Isolated Module DC DC Converter 2 Output 14V -14V 35mA, 35mA 4.5V - 5.5V Input |
| Current - Output (Max) | 35mA, 35mA | Applications | ITE (Commercial) |
