DSP1N5D12
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy DSP1N5D12 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy DSP1N5D12 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | DSP1N5D12 |
|---|---|
| Manufacturer | Bel |
| Description | DC DC CONVERTER +/-12V 1W |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Reference Price (In US Dollars) | 1 pcs | 5 pcs | 10 pcs | 25 pcs | |
|---|---|---|---|---|---|
| $8.587 | $8.52 | $8.455 | $8.323 | ||
| 50 pcs | 100 pcs | 250 pcs | 500 pcs | ||
| $7.926 | $7.266 | $7.134 | $7.028 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | DSP1N5D12 | Manufacturer | Bel |
|---|---|---|---|
| Description | DC DC CONVERTER +/-12V 1W | Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Quantity Available | 4793 pcs | Data sheet | DSP1D Series |
| Category | Power Supplies - Board Mount | Voltage - Output 3 | - |
| Voltage - Output 2 | -12V | Voltage - Output 1 | 12V |
| Voltage - Isolation | 700V | Voltage - Input (Min) | 4.5V |
| Voltage - Input (Max) | 5.5V | Type | Isolated Module |
| Size / Dimension | 0.77" L x 0.27" W x 0.40" H (19.6mm x 6.9mm x 10.2mm) | Series | DSP1 |
| Power (Watts) | 1W | Packaging | Bulk |
| Package / Case | 5-SIP Module | Other Names | 179-1076 DSP1N5D12-0A |
| Operating Temperature | -40°C ~ 85°C | Number of Outputs | 2 |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 20 Weeks | Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Features | - | Efficiency | 70% |
| Detailed Description | Isolated Module DC DC Converter 2 Output 12V -12V 40mA, 40mA 4.5V - 5.5V Input | Current - Output (Max) | 40mA, 40mA |
| Applications | ITE (Commercial) |
