HCPL-6630
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy HCPL-6630 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy HCPL-6630 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | HCPL-6630 |
|---|---|
| Manufacturer | Avago Technologies (Broadcom Limited) |
| Description | OPTOISO 1.5KV 2CH OPN COL 20LCCC |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 100 pcs | |
|---|---|---|---|---|---|
| $28.361 | $26.471 | $25.998 | $23.824 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | HCPL-6630 | Manufacturer | Avago Technologies (Broadcom Limited) |
|---|---|---|---|
| Description | OPTOISO 1.5KV 2CH OPN COL 20LCCC | Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Quantity Available | 1449 pcs | Data sheet | 6N134,81028,5962-9(8001,0855),HCPL-(56x,66x,268) |
| Category | Isolators | Voltage - Supply | 4.5 V ~ 5.5 V |
| Voltage - Isolation | 1500VDC | Voltage - Forward (Vf) (Typ) | 1.5V |
| Supplier Device Package | 20-LCCC | Series | - |
| Rise / Fall Time (Typ) | 35ns, 35ns | Propagation Delay tpLH / tpHL (Max) | 100ns, 100ns |
| Packaging | Tube | Package / Case | 20-CLCC |
| Output Type | Open Collector, Schottky Clamped | Other Names | 516-4223 HCPL-6630-ND |
| Operating Temperature | -55°C ~ 125°C | Number of Channels | 2 |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 6 Weeks | Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Inputs - Side 1/Side 2 | 2/0 | Input Type | DC |
| Detailed Description | Logic Output Optoisolator 10MBd Open Collector, Schottky Clamped 1500VDC 2 Channel 1kV/µs CMTI 20-LCCC | Data Rate | 10MBd |
| Current - Output / Channel | 25mA | Current - DC Forward (If) (Max) | 20mA |
| Common Mode Transient Immunity (Min) | 1kV/µs |
