Home > Products > Isolators > Optoisolators - Transistor, Photovoltaic Output > HCPL-6530

HCPL-6530

HCPL-6530
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy HCPL-6530 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number HCPL-6530
Manufacturer Avago Technologies (Broadcom Limited)
Description OPTOISO 1.5KV TRANS W/BASE CLCC
Lead Free Status / RoHS Status Contains lead / RoHS non-compliant
In Stock 1692 pcs
Reference Price
(In US Dollars)		1 pcs10 pcs25 pcs100 pcs
$26.516$23.96$22.363$21.245

Submit a Request For Quotation on quantities greater than those displayed.

Target Price:(USD)
Quantity:
Total:
$26.516

Product parameter

Part Number HCPL-6530 Manufacturer Avago Technologies (Broadcom Limited)
Description OPTOISO 1.5KV TRANS W/BASE CLCC Lead Free Status / RoHS Status Contains lead / RoHS non-compliant
Quantity Available 1692 pcs Data sheet 4N55, 5962-87679/90854, HCPL-x5xx
Category Isolators Voltage - Output (Max) 20V
Voltage - Isolation 1500VDC Voltage - Forward (Vf) (Typ) 1.55V
Vce Saturation (Max) - Turn On / Turn Off Time (Typ) 400ns, 1µs
Series - Rise / Fall Time (Typ) -
Packaging Tube Package / Case 20-CLCC
Output Type Transistor with Base Other Names 516-4259
HCPL-6530-ND
Operating Temperature -55°C ~ 125°C Number of Channels 2
Mounting Type Surface Mount Moisture Sensitivity Level (MSL) 1 (Unlimited)
Manufacturer Standard Lead Time 6 Weeks Lead Free Status / RoHS Status Contains lead / RoHS non-compliant
Input Type DC Detailed Description Optoisolator Transistor with Base Output 1500VDC 2 Channel
Current Transfer Ratio (Min) 9% @ 16mA Current Transfer Ratio (Max) -
Current - Output / Channel 8mA Current - DC Forward (If) (Max) 20mA

Related products

$57.777/pcsRFQ
$29.853/pcsRFQ
$152.089/pcsRFQ
$35.052/pcsRFQ
$46.021/pcsRFQ
$27.575/pcsRFQ
$228.167/pcsRFQ
$227.353/pcsRFQ
$38.969/pcsRFQ
$59.805/pcsRFQ
$42.678/pcsRFQ
$176.97/pcsRFQ
$160.204/pcsRFQ
$33.647/pcsRFQ
$34.722/pcsRFQ
HCPL-6531 Image
