Home > Products > Integrated Circuits (ICs) > PMIC - Full, Half-Bridge Drivers > SA12

SA12

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy SA12 with confidence from Components-World.HK, 1 Year Warranty

Dowload SA12 Details in PDF

Request a Quote

Part Number	SA12
Manufacturer	Apex Microtechnology
Description	IC MOTOR DRIVER PAR 12DIP
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 136 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs
Reference Price (In US Dollars)	$238.812	$229.968

Product parameter
Data sheet

Product parameter

Part Number	SA12	Manufacturer	Apex Microtechnology
Description	IC MOTOR DRIVER PAR 12DIP	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	136 pcs	Data sheet	SA12
Category	Integrated Circuits (ICs)	Voltage - Supply	14 V ~ 16 V
Voltage - Load	16 V ~ 200 V	Technology	Power MOSFET
Supplier Device Package	12-PowerDip	Series	-
Rds On (Typ)	400 mOhm (Max)	Packaging	Tube
Package / Case	12-PowerDIP, Module	Output Configuration	Half Bridge (2)
Other Names	598-1364 598-2140-5 598-2140-5-ND	Operating Temperature	-55°C ~ 150°C (TJ)
Mounting Type	Through Hole	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Manufacturer Standard Lead Time	11 Weeks	Load Type	Inductive, Capacitive
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Interface	PWM
Features	-	Fault Protection	Current Limiting, Over Temperature
Detailed Description	Half Bridge (2) Driver AC Motors, Piezo Devices Power MOSFET 12-PowerDip	Current - Peak Output	20A
Current - Output / Channel	15A	Base Part Number	SA*
Applications	AC Motors, Piezo Devices
