ACJS-MIV-5
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy ACJS-MIV-5 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy ACJS-MIV-5 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | ACJS-MIV-5 |
|---|---|
| Manufacturer | Amphenol Tuchel Electronics |
| Description | CONN JACK STEREO 1/4" |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $0.405 | $0.357 | $0.336 | $0.322 | $0.308 | |
| 250 pcs | 500 pcs | 1000 pcs | 2500 pcs | ||
| $0.28 | $0.252 | $0.224 | $0.203 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | ACJS-MIV-5 | Manufacturer | Amphenol Tuchel Electronics |
|---|---|---|---|
| Description | CONN JACK STEREO 1/4" | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 101331 pcs | Data sheet | ACJS-MIV-5 Drawing |
| Category | Connectors, Interconnects | Voltage - Rated | - |
| Thread Size | 3/8"-32 | Termination | Solder Eyelet(s) |
| Signal Lines | Stereo (3 Conductor, TRS) | Shielding | Unshielded |
| Series | M | Panel Hole Size | 0.382" (9.70mm) |
| Packaging | Bulk | Other Names | 889-1819 |
| Operating Temperature | -25°C ~ 70°C | Number of Positions/Contacts | 3 Conductors, 5 Contacts |
| Mounting Type | Panel Mount, Through Hole | Moisture Sensitivity Level (MSL) | Not Applicable |
| Mating Length/Depth | - | Manufacturer Standard Lead Time | 12 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Internal Switch(s) | Two Switches |
| Insulation Color | - | Industry Recognized Mating Diameter | 6.35mm (0.250", 1/4") - Headphone |
| Includes | 3 pcs - 1 Connector, 1 Nut, 1 Washer | Housing Material | Polybutylene Terephthalate (PBT) |
| Gender | Female | Features | Mounting Hardware |
| Detailed Description | 6.35mm (0.250", 1/4") - Headphone Phone Jack Stereo (3 Conductor, TRS) Connector Solder Eyelet(s) | Contact Material - Plating | Gold |
| Contact Material | Copper | Connector Type | Phone Jack |
| Cable Opening | - | Body Material | - |
| Body Color | Black | Actual Diameter | - |
