242209
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 242209 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 242209 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 242209 |
|---|---|
| Manufacturer | Amphenol Connex (Amphenol RF) |
| Description | CONN ADAPT MCX PLUG TO TNC JACK |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 50 pcs | ||||
|---|---|---|---|---|---|
| $8.837 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | 242209 | Manufacturer | Amphenol Connex (Amphenol RF) |
|---|---|---|---|
| Description | CONN ADAPT MCX PLUG TO TNC JACK | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 3980 pcs | Data sheet | 242209 Drawing |
| Category | Connectors, Interconnects | Style | Straight |
| Series | - | Packaging | Bulk |
| Other Names | ACX2155 | Operating Temperature | -65°C ~ 165°C |
| Mounting Type | Free Hanging (In-Line) | Mounting Feature | - |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Mating Cycles | - |
| Manufacturer Standard Lead Time | 10 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insertion Loss | - | Ingress Protection | - |
| Includes | - | Impedance | 50 Ohm |
| Frequency - Max | 6GHz | Features | - |
| Fastening Type | Snap-On, Threaded | Dielectric Material | Polytetrafluoroethylene (PTFE) |
| Detailed Description | Adapter Coaxial Connector MCX Plug, Male Pin To TNC Jack, Female Socket 50 Ohm | Convert To (Adapter End) | TNC Jack, Female Socket |
| Convert From (Adapter End) | MCX Plug, Male Pin | Conversion Type | Between Series |
| Center Gender | Female to Male | Center Contact Plating | Gold |
| Center Contact Material | Phosphor Bronze | Body Material | Beryllium Copper |
| Body Finish | Nickel | Adapter Type | Plug to Jack |
| Adapter Series | MCX to TNC |
