172313
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 172313 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 172313 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 172313 |
|---|---|
| Manufacturer | Amphenol Connex (Amphenol RF) |
| Description | CONN N JACK STR 50 OHM CRIMP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $3.959 | $3.787 | $3.443 | $3.271 | ||
| 100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
| $3.185 | $2.841 | $2.668 | $2.358 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 172313 | Manufacturer | Amphenol Connex (Amphenol RF) |
|---|---|---|---|
| Description | CONN N JACK STR 50 OHM CRIMP | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 13610 pcs | Data sheet | 172313 Drawing |
| Category | Connectors, Interconnects | Shield Termination | Crimp |
| Series | - | Packaging | Bulk |
| Other Names | ACX1440 | Operating Temperature | -65°C ~ 165°C |
| Number of Ports | 1 | Mounting Type | Panel Mount |
| Mounting Feature | Bulkhead - Front Side Nut | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Mating Cycles | 500 | Manufacturer Standard Lead Time | 9 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Insertion Loss | 0.15dB |
| Ingress Protection | Weatherproof | Includes | 6 pcs - 1 Connector, 1 Contact, 1 Ferrule, 1 Gasket, 1 Lockwasher, 1 Nut |
| Impedance | 50 Ohm | Housing Color | Silver |
| Frequency - Max | 6GHz | Features | - |
| Fastening Type | Threaded | Dielectric Material | Polytetrafluoroethylene (PTFE) |
| Detailed Description | N Type Connector Jack, Female Socket 50 Ohm Panel Mount Crimp or Solder | Contact Termination | Crimp or Solder |
| Connector Type | Jack, Female Socket | Connector Style | N Type |
| Center Contact Plating | Gold | Center Contact Material | Phosphor Bronze |
| Cable Group | RG-178, 178A, 178B, 196, 196A, M17/93-RG178 | Body Material | Brass |
| Body Finish | White Bronze |
