10112684-G03-04ULF
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 10112684-G03-04ULF with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 10112684-G03-04ULF with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 10112684-G03-04ULF |
|---|---|
| Manufacturer | Amphenol FCI |
| Description | CONN HEADER 4POS SGL HORIZ SMD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 72 pcs | 144 pcs | 504 pcs | |
|---|---|---|---|---|---|
| $0.497 | $0.396 | $0.378 | $0.31 | ||
| 1008 pcs | 5040 pcs | 10008 pcs | |||
| $0.275 | $0.241 | $0.229 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | 10112684-G03-04ULF | Manufacturer | Amphenol FCI |
|---|---|---|---|
| Description | CONN HEADER 4POS SGL HORIZ SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 98538 pcs | Data sheet | Minitek® 2.0MM SMT BrochureMinitek® II Series Spec10112684-zzz-yyyLF Drawing |
| Category | Connectors, Interconnects | Voltage Rating | 200V (AC/DC) |
| Termination | Solder | Style | Board to Board or Cable |
| Shrouding | Unshrouded | Series | Minitek® |
| Row Spacing - Mating | - | Pitch - Mating | 0.079" (2.00mm) |
| Packaging | Tube | Overall Contact Length | - |
| Other Names | 10112684G0304ULF 609-4381 |
Operating Temperature | -55°C ~ 125°C |
| Number of Rows | 1 | Number of Positions Loaded | All |
| Number of Positions | 4 | Mounting Type | Surface Mount, Right Angle |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Flammability Rating | UL94 V-0 |
| Mated Stacking Heights | - | Manufacturer Standard Lead Time | 8 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Insulation Material | Thermoplastic, Glass Filled |
| Insulation Height | 0.079" (2.00mm) | Insulation Color | Black |
| Ingress Protection | - | Features | - |
| Fastening Type | Push-Pull | Detailed Description | Connector Header Surface Mount, Right Angle 4 position 0.079" (2.00mm) |
| Current Rating | 2A (AC/DC) | Contact Type | Male Pin |
| Contact Shape | Square | Contact Material | Copper Alloy |
| Contact Length - Post | - | Contact Length - Mating | 0.157" (4.00mm) |
| Contact Finish Thickness - Post | 78.7µin (2.00µm) | Contact Finish Thickness - Mating | 30.0µin (0.76µm) |
| Contact Finish - Post | Tin | Contact Finish - Mating | Gold or Gold, GXT™ |
| Connector Type | Header | Applications | - |
