AON2411
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy AON2411 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy AON2411 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | AON2411 |
|---|---|
| Manufacturer | Alpha and Omega Semiconductor, Inc. |
| Description | MOSFET P-CH 12V 20A 8DFN |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 3000 pcs | ||||
|---|---|---|---|---|---|
| $0.093 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | AON2411 | Manufacturer | Alpha and Omega Semiconductor, Inc. |
|---|---|---|---|
| Description | MOSFET P-CH 12V 20A 8DFN | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 222705 pcs | Data sheet | AON2411 |
| Category | Discrete Semiconductor Products | Vgs(th) (Max) @ Id | 900mV @ 250µA |
| Vgs (Max) | ±8V | Technology | MOSFET (Metal Oxide) |
| Supplier Device Package | 8-DFN (2x2) | Series | - |
| Rds On (Max) @ Id, Vgs | 8 mOhm @ 12A, 4.5V | Power Dissipation (Max) | 5W (Ta) |
| Packaging | Tape & Reel (TR) | Package / Case | 8-PowerWDFN |
| Other Names | 785-1664-2 | Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 26 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Input Capacitance (Ciss) (Max) @ Vds | 2180pF @ 6V | Gate Charge (Qg) (Max) @ Vgs | 30nC @ 4.5V |
| FET Type | P-Channel | FET Feature | - |
| Drive Voltage (Max Rds On, Min Rds On) | 1.8V, 4.5V | Drain to Source Voltage (Vdss) | 12V |
| Detailed Description | P-Channel 12V 20A (Ta) 5W (Ta) Surface Mount 8-DFN (2x2) | Current - Continuous Drain (Id) @ 25°C | 20A (Ta) |
