AOC2802
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy AOC2802 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy AOC2802 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | AOC2802 |
|---|---|
| Manufacturer | Alpha and Omega Semiconductor, Inc. |
| Description | MOSFET 2N-CH 4WLCSP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
Product parameter
| Part Number | AOC2802 | Manufacturer | Alpha and Omega Semiconductor, Inc. |
|---|---|---|---|
| Description | MOSFET 2N-CH 4WLCSP | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 5107 pcs | Data sheet | |
| Category | Discrete Semiconductor Products | Vgs(th) (Max) @ Id | - |
| Supplier Device Package | 4-WLCSP (1.57x1.57) | Series | - |
| Rds On (Max) @ Id, Vgs | - | Power - Max | 1.3W |
| Packaging | Tape & Reel (TR) | Package / Case | 4-UFBGA, WLCSP |
| Operating Temperature | -55°C ~ 150°C (TJ) | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Input Capacitance (Ciss) (Max) @ Vds | - | Gate Charge (Qg) (Max) @ Vgs | 10.4nC @ 4.5V |
| FET Type | 2 N-Channel (Dual) Common Drain | FET Feature | Logic Level Gate |
| Drain to Source Voltage (Vdss) | - | Detailed Description | Mosfet Array 2 N-Channel (Dual) Common Drain 1.3W Surface Mount 4-WLCSP (1.57x1.57) |
| Current - Continuous Drain (Id) @ 25°C | - |
