XT424012
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy XT424012 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy XT424012 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | XT424012 |
|---|---|
| Manufacturer | Agastat Relays / TE Connectivity |
| Description | RELAY GEN PURPOSE DPDT 8A 12V |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 30 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $2.57 | $2.408 | $2.14 | $2.033 | ||
| 100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
| $1.926 | $1.712 | $1.605 | $1.498 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | XT424012 | Manufacturer | Agastat Relays / TE Connectivity |
|---|---|---|---|
| Description | RELAY GEN PURPOSE DPDT 8A 12V | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 24742 pcs | Data sheet | XT Product BrochureXT Series |
| Category | Relays | Turn On Voltage (Max) | 8.4 VDC |
| Turn Off Voltage (Min) | 1.2 VDC | Termination Style | Plug In |
| Switching Voltage | 400VAC - Max | Series | XT, SCHRACK |
| Release Time | 6ms | Relay Type | General Purpose |
| Packaging | Tube | Other Names | 1887200-2 PB1194 |
| Operating Temperature | -40°C ~ 70°C | Operate Time | 9ms |
| Mounting Type | Socketable | Manufacturer Standard Lead Time | 15 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Features | Insulation - Class F |
| Detailed Description | General Purpose Relay DPDT (2 Form C) 12VDC Coil Socketable | Contact Rating (Current) | 8A |
| Contact Material | Silver Nickel (AgNi) | Contact Form | DPDT (2 Form C) |
| Coil Voltage | 12VDC | Coil Type | Non Latching |
| Coil Resistance | 360 Ohms | Coil Power | 400 mW |
| Coil Current | 33.3mA |
