H6B-SDR-M20
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy H6B-SDR-M20 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy H6B-SDR-M20 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | H6B-SDR-M20 |
|---|---|
| Manufacturer | Agastat Relays / TE Connectivity |
| Description | CONN BASE SIDE ENTRY SZ6B M20 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $4.913 | $4.467 | $4.355 | $4.02 | ||
| 100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
| $3.797 | $3.462 | $3.239 | $2.971 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | H6B-SDR-M20 | Manufacturer | Agastat Relays / TE Connectivity |
|---|---|---|---|
| Description | CONN BASE SIDE ENTRY SZ6B M20 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 10206 pcs | Data sheet | H6B-SDR-(M,PG) Drawing |
| Category | Connectors, Interconnects | Thread Size | M20 |
| Style | Side Entry | Size / Dimension | 3.228" L x 2.047" W x 2.402" H (82.00mm x 52.00mm x 61.00mm) |
| Size | 6B | Series | HB |
| Packaging | Bulk | Other Names | A123628 T1620063120-000 |
| Operating Temperature | -40°C ~ 125°C | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 14 Weeks | Lock Location | Locking Clip (1) on Base Bottom |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Ingress Protection | IP65 - Dust Tight, Water Resistant |
| Housing Material | Aluminum Alloy, Die Cast | Housing Finish | Powder Coated |
| Housing Color | Gray | Features | Cover |
| Connector Type | Base - Box Mount |
