DTM13-12PA-12PB-R008
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy DTM13-12PA-12PB-R008 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy DTM13-12PA-12PB-R008 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | DTM13-12PA-12PB-R008 |
|---|---|
| Manufacturer | Agastat Relays / TE Connectivity |
| Description | CONN HEADER 24POS T/H R/A |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $7.702 | $6.954 | $6.662 | $6.246 | ||
| 100 pcs | 250 pcs | 500 pcs | |||
| $6.037 | $5.704 | $5.538 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | DTM13-12PA-12PB-R008 | Manufacturer | Agastat Relays / TE Connectivity |
|---|---|---|---|
| Description | CONN HEADER 24POS T/H R/A | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 7070 pcs | Data sheet | DTM13-12Px-12x-R008 Drawing |
| Category | Connectors, Interconnects | Voltage Rating | - |
| Termination | Solder | Style | Board to Cable/Wire |
| Shrouding | Shrouded - 4 Wall | Series | DTM |
| Row Spacing - Mating | - | Pitch - Mating | - |
| Packaging | Bulk | Overall Contact Length | - |
| Other Names | 1734-1131 1899781-5 DTM13-12PA12PBR008 DTM1312PA12PBR008 |
Operating Temperature | - |
| Number of Rows | 2 | Number of Positions Loaded | All |
| Number of Positions | 24 (12 + 12) | Mounting Type | Panel Mount, Through Hole, Right Angle |
| Moisture Sensitivity Level (MSL) | Not Applicable | Material Flammability Rating | - |
| Mated Stacking Heights | - | Manufacturer Standard Lead Time | 10 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Insulation Material | Plastic |
| Insulation Height | 1.378" (35.00mm) | Insulation Color | Gray |
| Ingress Protection | IP68/IP6K9K | Features | Mounting Flange |
| Fastening Type | Latch Holder | Detailed Description | Connector Header Panel Mount, Through Hole, Right Angle 24 (12 + 12) position |
| Current Rating | - | Contact Type | Male Pin |
| Contact Shape | Circular | Contact Material | - |
| Contact Length - Post | 0.112" (2.84mm) | Contact Length - Mating | - |
| Contact Finish Thickness - Post | - | Contact Finish Thickness - Mating | - |
| Contact Finish - Post | Tin | Contact Finish - Mating | Nickel |
| Connector Type | Header | Applications | Automotive |
