53241-1
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 53241-1 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 53241-1 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 53241-1 |
|---|---|
| Manufacturer | Agastat Relays / TE Connectivity |
| Description | CONN SPADE TERM 16-22AWG #8 RED |
| Lead Free Status / RoHS Status | Not applicable / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $0.203 | $0.191 | $0.172 | $0.153 | $0.147 | |
| 250 pcs | 500 pcs | 1000 pcs | 2500 pcs | ||
| $0.134 | $0.128 | $0.105 | $0.096 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 53241-1 | Manufacturer | Agastat Relays / TE Connectivity |
|---|---|---|---|
| Description | CONN SPADE TERM 16-22AWG #8 RED | Lead Free Status / RoHS Status | Not applicable / RoHS Compliant |
| Quantity Available | 237878 pcs | Data sheet | 53241 |
| Category | Connectors, Interconnects | Wire Gauge | 16-22 AWG |
| Width - Outer Edges | 0.244" (6.20mm) | Tongue Inside Opening | 0.164" (4.17mm) |
| Termination | Crimp | Terminal Type | Spring, Snap |
| Stud/Tab Size | 8 Stud | Series | Plasti-Grip |
| Packaging | Bulk | Other Names | 53241-1-ND A27441 |
| Mounting Type | Free Hanging (In-Line) | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Material - Insulation | Poly-Vinyl Chloride (PVC) | Length - Termination | 0.416" (10.57mm) |
| Length - Ring Center to Termination | 0.281" (7.14mm) | Length - Overall | 0.872" (22.15mm) |
| Lead Free Status / RoHS Status | Not applicable / RoHS Compliant | Insulation Diameter | 0.105" ~ 0.140" (2.67mm ~ 3.56mm) |
| Insulation | Insulated | Features | Serrated Termination |
| Detailed Description | Red 8 Stud Spade Terminal Connector Crimp 16-22 AWG | Contact Material | Brass |
| Contact Finish | Tin | Color | Red |
