5-1747147-4
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 5-1747147-4 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 5-1747147-4 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 5-1747147-4 |
|---|---|
| Manufacturer | Agastat Relays / TE Connectivity |
| Description | DZ5200 REC ASSY 3P 10.16MM PITCH |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 11 pcs | 33 pcs | 55 pcs | |
|---|---|---|---|---|---|
| $4.091 | $3.718 | $3.626 | $3.347 | ||
| 110 pcs | 253 pcs | 506 pcs | 1001 pcs | ||
| $3.161 | $2.882 | $2.696 | $2.473 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 5-1747147-4 | Manufacturer | Agastat Relays / TE Connectivity |
|---|---|---|---|
| Description | DZ5200 REC ASSY 3P 10.16MM PITCH | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 14706 pcs | Data sheet | 1747147 Drawing |
| Category | Connectors, Interconnects | Voltage Rating | 600V |
| Termination | Solder | Style | Board to Board |
| Series | Dynamic DZ5200 | Row Spacing - Mating | - |
| Pitch - Mating | 0.400" (10.16mm) | Packaging | Tube |
| Other Names | A120715 | Operating Temperature | -55°C ~ 105°C |
| Number of Rows | 1 | Number of Positions Loaded | All |
| Number of Positions | 4 | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Flammability Rating | UL94 V-0 |
| Mated Stacking Heights | - | Manufacturer Standard Lead Time | 21 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Insulation Material | Polyester, Glass Filled |
| Insulation Height | 0.551" (14.00mm) | Insulation Color | Black |
| Ingress Protection | - | Features | Board Guide, Board Lock |
| Fastening Type | Push-Pull | Detailed Description | 4 Position Receptacle Connector Through Hole Gold |
| Current Rating | 30A | Contact Type | Female Blade Socket |
| Contact Shape | Rectangular | Contact Material | Phosphor Bronze |
| Contact Length - Post | 0.150" (3.81mm) | Contact Finish Thickness - Post | 78.7µin (2.00µm) |
| Contact Finish Thickness - Mating | 8.00µin (0.203µm) | Contact Finish - Post | Tin |
| Contact Finish - Mating | Gold | Connector Type | Receptacle |
| Applications | - |
