5-1747145-3
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 5-1747145-3 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 5-1747145-3 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 5-1747145-3 |
|---|---|
| Manufacturer | Agastat Relays / TE Connectivity |
| Description | DZ5200 HDR ASSY 4P 10.16MM PITCH |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 15 pcs | 30 pcs | 60 pcs | |
|---|---|---|---|---|---|
| $2.952 | $2.824 | $2.567 | $2.439 | ||
| 105 pcs | 255 pcs | 510 pcs | 1005 pcs | ||
| $2.374 | $2.118 | $1.989 | $1.758 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 5-1747145-3 | Manufacturer | Agastat Relays / TE Connectivity |
|---|---|---|---|
| Description | DZ5200 HDR ASSY 4P 10.16MM PITCH | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 17989 pcs | Data sheet | 1747145 Drawing |
| Category | Connectors, Interconnects | Voltage Rating | 600V |
| Termination | Solder | Style | Board to Cable/Wire |
| Shrouding | Shrouded - 4 Wall | Series | Dynamic DZ5200 |
| Row Spacing - Mating | - | Pitch - Mating | 0.400" (10.16mm) |
| Packaging | Tube | Overall Contact Length | - |
| Other Names | A120714 | Operating Temperature | -55°C ~ 105°C |
| Number of Rows | 1 | Number of Positions Loaded | All |
| Number of Positions | 3 | Mounting Type | Through Hole, Right Angle |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Flammability Rating | UL94 V-0 |
| Mated Stacking Heights | - | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insulation Material | Thermoplastic, Polyester, Glass Filled | Insulation Height | 0.630" (16.00mm) |
| Insulation Color | Black | Ingress Protection | - |
| Features | Board Guide, Board Lock | Fastening Type | Detent Lock |
| Detailed Description | Connector Header Through Hole, Right Angle 3 position 0.400" (10.16mm) | Current Rating | 30A |
| Contact Type | Tab | Contact Shape | Rectangular |
| Contact Material | Copper Alloy | Contact Length - Post | 0.150" (3.81mm) |
| Contact Length - Mating | - | Contact Finish Thickness - Post | 78.7µin (2.00µm) |
| Contact Finish Thickness - Mating | 8.00µin (0.203µm) | Contact Finish - Post | Tin |
| Contact Finish - Mating | Gold | Connector Type | Header |
| Applications | General Purpose, Industrial |
