228217-1
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 228217-1 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 228217-1 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 228217-1 |
|---|---|
| Manufacturer | Agastat Relays / TE Connectivity |
| Description | CONN SMB JACK STR 50 OHM CRIMP |
| Lead Free Status / RoHS Status | Contains lead / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | ||||
|---|---|---|---|---|---|
| $5.986 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | 228217-1 | Manufacturer | Agastat Relays / TE Connectivity |
|---|---|---|---|
| Description | CONN SMB JACK STR 50 OHM CRIMP | Lead Free Status / RoHS Status | Contains lead / RoHS Compliant |
| Quantity Available | 6388 pcs | Data sheet | 228217-1 |
| Category | Connectors, Interconnects | Voltage Rating | 335V |
| Shield Termination | Crimp | Series | - |
| Packaging | Bulk | Other Names | 228217-1-ND A113175 |
| Operating Temperature | -65°C ~ 165°C | Number of Ports | 1 |
| Mounting Type | Panel Mount | Mounting Feature | Bulkhead - Front Side Nut |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Mating Cycles | 500 |
| Manufacturer Standard Lead Time | 14 Weeks | Lead Free Status / RoHS Status | Contains lead / RoHS Compliant |
| Insertion Loss | 0.3dB | Ingress Protection | - |
| Includes | 6 pcs - 1 Connector, 1 Contact, 2 Ferrule, 1 Lockwasher, 1 Nut | Impedance | 50 Ohm |
| Housing Color | Silver | Frequency - Max | 4GHz |
| Features | - | Fastening Type | Snap-On |
| Dielectric Material | Polytetrafluoroethylene (PTFE) | Detailed Description | SMB Connector Jack, Male Pin 50 Ohm Panel Mount Crimp |
| Contact Termination | Crimp | Connector Type | Jack, Male Pin |
| Connector Style | SMB | Center Contact Plating | Gold |
| Center Contact Material | - | Cable Group | RG-174, 188, 316 |
| Body Material | - | Body Finish | Nickel |
